Victron Energy Lynx Power In & Class-T Power In (Modular DC Busbar)

The Lynx Power In is a modular DC busbar — the simple, solid backbone that ties your batteries, loads, and chargers together in a Victron Lynx Distribution system. It carries a positive and negative busbar with four connections plus a ground point, and is rated for a nominal 1000 A at 12 V / 24 V / 48 V. It can be used on its own or clicked together with other Lynx modules (Distributor, Shunt VE.Can, Smart BMS).

Two versions

• Lynx Power In — a plain positive/negative busbar with four battery/load/charger connections and a ground connection. No fuses or monitoring; just clean, high-current distribution.
• Lynx Class-T Power In — adds connections for two Class-T fuses so it can connect and fuse up to two strings of lithium batteries. Class-T is the fuse type recommended for lithium because of its high interrupt rating. Class-T fuses (225 A, 250 A, 350 A, 400 A) are sold separately.

Note: the “M10” designation refers to the busbar connection joints where Lynx modules join to each other — the fuse and cable connections are always M8.

Part of the Lynx Distribution system

Pair the Power In with a Lynx Distributor (fused outputs), a Lynx Shunt VE.Can (battery monitoring + main fuse), or a Lynx Smart BMS (lithium battery management) to build a tidy, modular DC bus.

Blue Marine is an authorized Victron Energy dealer — ships brand-new with the full 5-year Victron warranty, free shipping, and local pickup available.
