Victron Energy EasySolar-II GX 48/6500 All-in-One Solar Inverter/Charger 230V (Euro)
Free shipping over $49
60-day hassle-free returns
The EasySolar-II GX packs a complete solar power system into one wall-mounted box: a MultiPlus-II 48/6500 inverter/charger, a SmartSolar MPPT 250/100 solar charge controller, and a built-in GX control hub with display and Wi-Fi — prewired together at the factory. Land the battery cables, the PV array, and the AC connections, and the system is essentially built. This is the 6.5 kVA / 48V model — a 230 V unit (50 Hz, adjustable to 60 Hz) for European-spec and 230V off-grid systems, and usable in US installs paired with a Victron Autotransformer for 120/240V split-phase.
Who the EasySolar-II GX fits
- Off-grid homes and cabins on 230V — 6,000 W continuous with an 11 kW one-minute peak covers a household's worth of loads, and the MPPT takes up to 5,800 W of PV.
- ESS / self-consumption on a 230V grid — run grid-parallel or grid-in-line topologies, optimize self-consumption, and keep critical loads alive through outages.
- US split-phase systems via an Autotransformer — configured for 60 Hz and paired with a Victron Autotransformer, it delivers balanced US 120/240V split-phase — one all-in-one solar box plus one transformer.
- Installers who value commissioning time — one enclosure to mount, no interconnect wiring between inverter, MPPT, and GX, and monitoring is on VRM out of the box via Ethernet or built-in Wi-Fi.
What's inside
MultiPlus-II 48/6500/100-50 inverter/charger
6,000 W continuous at 77 °F (25 °C), 5,700 W at 104 °F, and an 11 kW one-minute peak for motor and compressor starts. The 4-stage adaptive charger delivers up to 100 A into the bank from grid or generator, and PowerControl / PowerAssist make the most of a limited AC connection through the 50 A transfer switch.
SmartSolar MPPT 250/100 charge controller
Up to 5,800 W of PV at up to 250 V open-circuit, charging at up to 100 A with 99% peak efficiency. The MPPT's DC output is factory-paralleled with the inverter/charger's DC connection, and the MultiPlus-II's on/off control also commands the MPPT.
Built-in GX device with display and Wi-Fi
A 2×16-character display reads battery, inverter, and solar parameters, and the integrated GX brings BMS-Can (for CAN-bus managed lithium batteries), USB, Ethernet, VE.Direct, and Wi-Fi. Configuration and monitoring run through the display, VictronConnect, or the free VRM portal — including remote firmware updates and full ESS control.
Full technical specifications
| Transfer switch / max AC input | 50 A |
| DC input voltage range | 38–60 V (48V nominal) |
| AC output | 230 VAC ± 2%, 50 Hz ± 0.1% (adjustable to 60 Hz) |
| Continuous output at 77 °F (25 °C) | 6,000 W |
| Continuous output at 104 °F / 131 °F (40/55 °C) | 5,700 W |
| Continuous output at 149 °F (65 °C) | 4,600 W |
| Time-limited power (cold start) | 6.5 kW for 3 h; 8 kW for 1 h |
| Peak power | 11 kW for 1 minute |
| Maximum apparent feed-in power | 6 kW |
| Maximum efficiency (inverter) | 96% |
| Zero-load power | 25 W (14 W in AES mode; 7 W in Search mode) |
| Charger — AC input | 187–265 VAC, 45–65 Hz |
| Charge voltages (default) | Absorption 57.6 V / float 55.2 V / storage 52.8 V |
| Maximum charge current | 100 A at 77 °F (95 A at 104 °F) |
| Compatible battery chemistries | Lithium, lead-acid, zinc-bromine, and more — charger fully configurable to the battery manufacturer's specification |
| MPPT — maximum output current | 100 A |
| MPPT — maximum PV power | 5,800 W |
| MPPT — maximum PV open-circuit voltage | 250 V |
| MPPT — maximum efficiency | 99% (20 mA self-consumption) |
| GX interfaces | BMS-Can, USB, Ethernet, VE.Direct, Wi-Fi; 2×16-character display |
| Auxiliary output | Yes (32 A) — live only when AC input is present |
| External AC current sensor | Optional, 100 A |
| Programmable relay | Yes |
| Battery temperature sensor | Optional (ASS000001000) |
| Operating range | −4 to +149 °F (−20 to +65 °C), fan-assisted cooling; max 95% humidity; max altitude 6,562 ft (2,000 m) |
| Enclosure | Steel, blue RAL 5012; IP21; battery M8 bolts; PV M6 bolts; AC screw terminals 16 mm² (6 AWG) |
| Weight | 88.2 lb (40 kg) |
| Dimensions (H×W×D) | 26.4 × 12.6 × 10.6 in (670 × 320 × 270 mm) |
| Safety standards | EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2 |
Good to know before you order
- 230 VAC output, 50 Hz by default and adjustable to 60 Hz. For US 120/240V split-phase, pair it with a Victron Autotransformer — it creates the balanced split-phase output and handles the neutral-ground bond.
- The BMS-Can port connects CAN-bus managed batteries; note it is not a VE.Can port.
- The battery temperature sensor is optional on this model (order number ASS000001000).
Resources
The full Victron datasheet and product manual are in Manuals & Datasheets below on this page. Planning a full off-grid build around it — or the Autotransformer split-phase pairing? Schedule an online consultation with one of our ABYC-certified Advisors and we'll spec the array, bank, and protection with you.
Warranty
Covered by Victron Energy's 5-year limited warranty. Blue Marine is an authorized Victron Energy dealer and handles the claim process for you — email support@bluemarine.com.
