ePropulsion Spirit 1.0 Plus 3HP Electric Outboard Motor
Lithium batteries & products containing lithium batteries are non returnable
The Spirit 1.0 Plus is a portable 3 HP-class electric outboard motor designed for dinghies, fishing boats, tenders, and sailboats. Engineered for both convenience and performance, it delivers clean, quiet power with the ease of electric propulsion. Its modular design makes transport simple, while its intuitive controls ensure a smooth on-water experience for boaters of all levels.
Powered by an optional 1276 Wh lithium-ion battery (sold separately), the Spirit 1.0 Plus offers exceptional range and reliability. The lightweight battery—just 19 lbs (8.7 kg)—is fully integrated and floats for added safety and peace of mind if accidentally dropped in the water.
Key Features:
-
Electric Start: One-button start for effortless operation—no pull cords required.
-
Digital Display: Real-time access to vital stats like power output, remaining run-time, battery life, and voltage.
-
Magnetic Kill Switch: Provides immediate shutdown in emergencies for user safety.
-
Stepless Throttle Control: Smooth, responsive throttle with adjustable power settings for a customized ride.
-
Child and Rental Safety: Limit maximum power output for added control in family or rental settings.
-
Ambidextrous Design: Operate comfortably with either hand.
What's Included:
-
Spirit 1.0 Plus motor shaft
-
Tiller
-
Two kill switches
-
Battery charger
-
Mounting pins
Note: Battery is not included and must be purchased separately.
Whether you're navigating marinas, exploring quiet coves, or heading out for a day of fishing, the Spirit 1.0 Plus offers an efficient, eco-friendly alternative to traditional gas-powered motors—with none of the noise or fumes.
Steps to Determine the Right Shaft Length
1. Measure Your Transom Height
The transom height is the vertical distance from the top of your boat's transom to the bottom of the hull. Use a measuring tape to obtain this measurement accurately.
2. Add the Propeller Radius
Consult your motor's user manual to find the radius of the propeller. For example, the Spirit 1.0 Evo has a propeller radius of approximately 5.5 inches (14 cm).
3. Add Clearance for Water Flow
Include an additional 4 inches (10 cm) to ensure proper water flow and prevent cavitation.
Calculation Example:
If your transom height is 21 inches:
-
Transom Height: 21 inches
-
Propeller Radius: 5.5 inches
-
Clearance: 4 inches
Total Required Shaft Length:
21 + 5.5 + 4 = 30.5 inches. In this case, a long shaft option (approximately 29.5 inches) would be suitable.
ePropulsion Shaft Length Options
| Model | XS (in) | S (in) | L (in) |
|---|---|---|---|
| Spirit Series | 20.7 | 24.6 | 29.5 |
| Navy Series | N/A | 25.0 | 29.9 |
Note: The Extra Short (XS) shaft is available only for the Spirit series.
