ePropulsion I-10 — 10 kW, 96V Electric Inboard
The I-10 is the compact end of ePropulsion's next-generation 96-volt I-Series inboards — clean, whisper-quiet electric propulsion for sailboats, small cruisers, and tenders. It consolidates five components (motor, gearbox, motor controller, system control unit, and cooling) into one tidy, plug-and-play unit, so it drops into new builds and electric repowers with minimal wiring and fuss.
Why the I-Series
- 5-in-1 integration — motor, gearbox, controller, control unit and cooling in one unit; about 60% less space than a comparable combustion engine.
- Light — 99 lb; up to 65% lighter than combustion and ~30% lighter than comparable electric inboards.
- Hydrogeneration — recharges the battery from propeller-driven water flow while sailing.
- Plug-and-play pre-connected wiring; connected via the ePropulsion cloud Connectivity Service.
- Unified Smart Throttle + 5″ display for an intuitive helm; dual-motor route planning supported.
One connected system — eSSA
The I-10 runs on ePropulsion's eSSA architecture. Complete the system with a 96V G-Series battery (G102-100 or G102-230), a G-Series charger or 2 kW MPPT solar controller, and your choice of Smart control/display. Components connect with keyed eSSA cables. Our advisors will size battery, charging and controls with you.
You also need a 12V battery. Beyond the 96V propulsion pack, the I-Series uses a separate 12V supply for its controls, display, and electronics. An included 96V→12V DC-DC module keeps it charged from the propulsion pack. The 12V battery is not included and should provide at least 18 A continuous discharge — we'll spec it with the rest of your system.
Specifications
| Rated input power | 10 kW |
| Rated output torque | 52 lb·ft (70 N·m) |
| Propulsion voltage | 96 VDC nominal (86–115 VDC) |
| Control supply | 12 VDC (9–16 VDC) — separate 12V battery required |
| Weight | 99 lb (45 kg) |
| Dimensions (L×W×H) | 22.2 × 11.6 × 15.0 in |
| Cooling | Air cooling |
| Rated rotational speed | 1200–1700 rpm |
| Operating temperature | 23–131°F (−5 to 55°C) |
| Mounting | Four-point elastic rubber mount (vibration damping) |
| Connectivity | ePropulsion Connectivity Service supported |
What's in the box
- I-10 inboard motor (pre-connected internal wiring)
- High-voltage power cable (2 m)
- 96V→12V DC-DC module and 12V power cable
- Bus Box
- eSSA communication cable and terminators
To complete the system you'll add a 96V G-Series battery, a 12V battery (≥18 A continuous), a charger, and your chosen control/display.
Applications
Sailing yachts, multihulls, narrowboats, small leisure powerboats, tenders, and light workboats moving to clean electric inboard power.
Warranty
Covered by ePropulsion's 24-month limited warranty (from delivery to the first end customer) against defects in materials and workmanship under normal recreational use with proper installation and maintenance. Commercial or professional use is covered by your local statutory warranty instead. Blue Marine is an authorized ePropulsion dealer and will help with any claim.
Support
Professional installation is strongly recommended. Schedule an online consultation and our ABYC-certified advisors will spec the battery, 12V supply, charging and controls as one system, and advise on repower fit.
